Transparent Powder Coating

It could be fantasy colors according to special fabrication procession and the coatings is sparkling and crystal-clear, the base color could be correctly reflected, all the hardware are applied to.

: Colorful, bright in color

: Great in glossiness wonderful in levelling

: Crystal clear, which could reflect the base color correctly

: Non-toxic and safe: food grade.

: Good in mechanical and physical properties.

Product details

Operational processes and parameters

Pre-treatment：Degreasing, rust removal, sandblasting, phosphating, silane treatment, or ceramic coating, etc.

Attention：Before spraying, please ensure that the substrate is thoroughly degreased and rust-free, with no impurities, water stains, or residual liquid.

Note：Acid washing and sandblasting the substrate can enhance the adhesion between the coating and the substrate.

Spraying requirements

Cured condtions：15 mins. at 180℃ metal temperature

Cured Film Thickness：30-60um.

Storage Stability

Keep storage environment well-ventilated and dry, with temperatures not exceeding 27°C.

Properties parameter

Items	Standard	Result
Impact	ASTM D-2794	80in.ibf（Direct)/20in.ibf（indirect)
Pencil Hardness	ASTM D3363	≧2H
Adhesion(100cells)	ASTM D-3359	Full pass (5B)
Flexibility	ASTM D522	3/16'inch
Salt spray resistance(5%Nacl)	ASTM B-117	500H,Corrsion,≤3mm,
QUV Resistance(UV340)	ASTM G-154	504H ΔE≤4
